1) tip the piston slightly as you insert it into the bore, square it to the bore as you feel the piston start to slip past the seal. 2) insert the piston into the bore square and slightly twist to get the seal to slip onto the piston. Either way push the piston all the way to the bottom of bore once it passes the seal.
